Perlan AUT

Perlan AUT-NT for glass leaves * Automation for Perlan on glass doors with up to 80 kg leaf weight

Perlan AUT-NT Glass Automation set Perlan AUT-NT at a glass door in a residential building.
  • For automation of Perlan internal sliding doors with a leaf weight of max. 80 kg
  • Adjustable comfort and safety functions
  • Max. speed can be set up to 0.3 m/s
  • Low-energy sliding door drive in accordance with EN 16005
Contact us

Application Areas

  • Sliding door automation for Perlan on light to medium-weight interior doors
  • Particularly suitable for private living areas
  • Single and multiple-leaf glass sliding doors
  • Mounting to the wall and also to the ceiling via additional ceiling brackets
  • Not for escape or rescue routes

Technical data

Perlan AUT-NT for glass leaves
Leaf material Glass
Leaf weight (max.) 80 kg
Number of leaves 1-leaf, 2-leaf
Leaf width (min.) 500 mm
Leaf width (max.) 1640 mm
Leaf thickness from 8 mm
Leaf thickness to 12 mm
Track geometry straight
Type of installation Wall, Ceiling
DIN direction left / right
Telescope No
Automated Yes
Side panel No
