Door control

GEZE ActiveStop integrated * Door damper on both sides for timber swing doors in the indoor area

  • Door opening angle with variable adjustment from 80°-140°
  • Can be used for right and left hand doors without conversion
  • Soft opening and closing of doors up to max. 45 kg leaf weight
  • Gentle stopping, quiet closing and comfortable keeping open of doors
  • Practically eliminates slamming doors, trapped fingers, and damage to walls and furniture
  • Secure holding of the door when open, meaning no door is stopper necessary
Show more
  • Opening and latching speed when installed can be set via a valve
  • Integrated safety valve offers overload protection
Contact us

Door damper on both sides for timber swing doors in the indoor area

Application Areas

  • Right and left timber single-action doors indoors
  • Room doors with high access convenience
  • Single-action doors up to 1100 mm leaf width
  • Integrated installation in the door leaf
  • Barrier-free access in accordance with DIN 18040

Product specifications

GEZE ActiveStop integrated
Depth 28 mm
Height 64 mm
Leaf weight (max.) 45 kg
Leaf width (max.) 1100 mm
Leaf material Wood
Leaf thickness from 38 mm
Identical design for DIN left and DIN right Yes
Rebate space approx. 6 mm clearance in handle area
Installation type concealed
Draw-in damper in direction of closing movement from 25 °
Free swing area 25 ° - 60 °
Draw-in damper in direction of opening movement from 60 °
Door opening angle 80 ° - 140 °
Secured final position Safe holding of the door in the open position, no door stop needed
Safety valve againts overload Yes
Latch blockers Supplied by GEZE
